600 - 700 Series Pivot Squeeze
Bale Bed by DewEze
Introducing the 600 - 700 Series Pivot Squeeze, the newest DewEze Bale Bed. Our Pivot Squeeze is built with the same strength and style of the industry-leading Parallel Squeeze, and includes innovative options like the new Swivel Spinners and the large 110" opening and narrow 34" closing of the DewEze Pivot Squeeze arms.
The only bale bed manufacturer to offer a variety of squeeze styles, this synchronized squeeze option gives you a greater range of motion from 34 to 110 inches wide.
Our patented 12” swivel spinners keep the bale parallel while unrolling, converting into greater accuracy and coverage while feeding.
The sturdy, steal recessed gooseneck ball offers a 40,000 lb. hauling capacity. A receiver hitch and D-rings complete the package to assist with all hauling needs.
The only flatbed to exclusively feature a clutch pump kit manufactured in house, DewEze hydraulic systems run independent of your truck’s transmission. The kit components are designed for your truck’s horsepower requirements.
At Harper Industries, we are proud of the products we manufacture and guarantee satisfactory customer service. All bale beds include a two-year warranty, and one-year warranty on hydraulic systems.
Change the way you work in the field with the DewEze wireless remote. Designed to run the functions of the bed from the comfort of your cab, or out in the field, regardless of the weather.
All DewEze Flatbeds are finished by applying Gatorhyde lining to the deck surface. This polyurethane coating creates a corrosion-resistant surface, designed to withstand treacherous weather and built to last.
High-quality LED lights transform your bed’s style and lighting performance. You won’t miss sharp light beams glowing from the headache rack, side clearance and tail/brake lights.
All 600/700 Series bale beds include dual lift cylinders with a lift capacity of 3,100 lbs. Both the cylinders and tailboard are removable for servicing.
Move or operate rear-mounted hydraulic equipment by simply tapping into DewEze’s fittings.
Solid dummy arms with tie-down hooks assist you with your hauling needs. The dummy arms create side rails on the perimeter of the bed when the bale arms are not in use.
Now extending an additional 20 inches, the XRM places bales in round feeders or stacks bales in a row with ease.
Made from the same heavy steel construction, across-the-bed and underbelly toolbox options complete your storage needs. The underbelly toolbox features a step and rubber mat.
Fixed Position Light Brackets or Pivoting Light Brackets lead the way during after-hour tasks. Control the Pivot Light Kit to illuminate anywhere you want to feed, or fold it flush with the headache rack when not in use.
Combine the lifting power of both loading arms to pick up pipe or pull yourself out of a mud hole.
600 - 700 Series Pivot Squeeze Downloads
Bale Beds Downloads
|Truck Model||All Short Bed||All Long Bed||Varies with make||'99 & Newer||'07 & Newer||'99 & Newer||'07 & Newer||'99 & Newer||'07 & Newer|
|Truck Brand||All||All||All***||Ford||Dodge||Ford||All||Ford / Chevy||All|
|Set-up Code||Box Removal||Box Removal||Box Removal||Cab & Chassis||Cab & Chassis||Cab & Chassis||Cab & Chassis||Cab & Chassis||Cab & Chassis|
|Truck Model||Shortbox||Varies with make||All Long Bed||F-450 & F-550||4500 & 5500||F-450 & F-550||4500 & 5500|
|Set-up Code||Box Removal||Box Removal||Box Removal||Cab & Chassis||Cab & Chassis||Cab & Chassis||Cab & Chassis|
(All) truck brands referenced include Dodge, Ford and Chevrolet.
*Each bed has a lift capacity of 3,100 lbs., a 10 gallon reservoir, a 2-year warranty on the flatbed, and a 1-year warranty on the hydraulic and electrical system.
**Any Dual Wheel Cab Chassis truck '98 and older will need a 682 or 687 model depending on the cab-to-axle measurement.
***Ford 2017+, Chevy 2011+, Dodge 2014+ for 2500
